Salt/ Fog 3dB Hybrid Coupler 4.3-10 Female 694-2700 (Microlab CA-84KE)
Salt/ Fog 3dB Hybrid Coupler 4.3-10 Female 694-2700 (Microlab CA-84KE)
Buy Now, Pay Later with No Interest if paid in full within 6-12 months. Choose Klarna payment option at the checkout for details of this, and other long-term low-interest financing options.
Free Lifetime Support. SKU / Model: CA-84KE
1(855)846-2654
Need installation quote, or help with designing a custom solution? Submit a request for quote.
- Description
- Reviews
- Questions & Answers
- Make An Offer
- Warning
Description
Product Description
Salt/ Fog 3dB Hybrid Coupler 4.3-10 Female 694-2700 (Microlab CA-84KE). Microlab Hybrid Couplers have been designed to meet the special needs of the wireless market. They are most commonly used to combine two wireless carriers in the band to a single antenna feed or distribution cable. This requires the termination of one output port in 50O and results in a 3 dB loss in each signal. In situations where two similar feeds are required, as required for an in-building application, both outputs may be used eliminating the need for a termination and the 3 dB loss. The CA-84K Series is designed for harsh outdoor applications in corrosive salt fog environments. The CA-84KE has 4.3-10 female terminations and has a PIM rating of -161dBc. RoHS Compliant. RoHS stands for Restriction of Hazardous Substances. RoHS restricts the use of specific hazardous materials found in electrical and electronic products (known as EEE). UPC: 646444281638. SKU: CA84KE.
Features.
- Standard Bandwidth for commercial wireless applications.
- Guaranteed Low PIM.
- 30dB Port to Port Isolation.
- Models for Outdoor Environments.
- Low VSWR and Dissipative Loss.
- Rail Standard EN 50155:2007 (Class T1) Certified.
- High Reliability, Moisture sealed.
- Easy mounting to pole or wall.
What is low PIM?
PIM stands for Passive Inter-Modulation. Its unit of measurement is Decibel (dB). In essence, its meaning is, "unwanted signals generated by non-linear mixing of 2 or more frequencies". Therefore, "high PIM" results in weaker cell reception output and a limited bandwidth that supports fewer users. On other hand, "low PIM" means stronger signals with higher bandwidth to support more users simultaneously. For lower PIM, the low PIM hardware connections are designed in a precise manner for achieving near-perfect, seamless connectivity. To minimize PIM further, testing is also required to make sure low PIM hardware is installed tightly or perfectly, as intended. Read more about low PIM antennas and cable connectors.
Specifications:
| Frequency Range | 694-2700 MHz |
|---|---|
| Coupling | 3 dB nominal. |
| Coupled Loss (dB) | 3 |
| Directivity | 30 dB |
| Maximum Power | 80W |
| Maximum VSWR | 1.20:1 |
| Isolation | >30 |
| PIM Typical | -161 dBc |
| RF Connectors | 7/16 Female |
| Ingress Protection | IP67 |
| Temperature Range | -35 to 65 degrees centigrade |
| Weight | 1.44 lbs |
| Item Width | 5.99 inches |
| Item Length | 3.21 inches |
| Item Height | 1 inch |
| Manufacturer | Microlab / FXR |
