Black 30 Degrees Sector Directional Antenna (16 dBi, 50 Ohm)

Black 30 Degrees Sector Directional Antenna (16 dBi, 50 Ohm)

  • Regular price $900.00 USD Sale price$799.99 USD
Best Price Guarantee. [1, 2, 3]
  • Product Url
  • This field is required. Please enter a value.

  • This field is required. Please enter a value.

  • This field is required. Please enter a value.

  • This field is required. Please enter a value.

  • *These fields required. [2] May exclude very large size items because we offer free shipping so our actual cost may be too high due to the size/ weight of item to be able to match the price. [3] Request must be made before order placement. Not valid after order placed. Other restrictions may apply. Please contact us for details.

Buy Now, Pay Later with No Interest if paid in full within 6-12 months. Choose Klarna payment option at the checkout for details of this, and other long-term low-interest financing options.

Free Lifetime Support. SKU / Model: AFC08ANT0931BLB1MP

Best Price Guarantee [1 2 3]

Call for FREE consultation:

1(855)846-2654

Need installation quote, or help with designing a custom solution? Submit a request for quote.

  • Description
  • Reviews
  • Questions & Answers
  • Make An Offer
  • Warning

Description

Product Description

Black color premium quality Multi-Polarized High Gain 30 degree directional sector antenna (700-2700MHz) is constructed of UV stabilized polymers and high grade aluminum for extremely long service life in the most demanding conditions. With a 30˚ directional pattern, it provides exceptional 16 dBi high gain effective power and is ideal for indoor and outdoor deployments where a sectorized approach is required to accommodate clients in a variety of points. The Sector 30 700-2700 MHz can easily be mast or wall mounted with available mounting hardware. Multi-Polarized antenna technology provides unequalled wireless communication in "Real World" obstructed non-line-of-sight (NLOS) environments.

Features.

  • Multi-Polarized.
  • Obstruction Penetrating TX/RX.
  • Built In Spatial Diversity.
  • Excellent F/B (28 dB).
  • Light Weight/Low Wind Load.
  • Down tilt Mast Mounting Hardware Included.

Applications.

  • 700-2700 MHz Wireless Systems.
  • Point-to-Point and Multipoint Systems.
  • Outdoor DAS.
  • LTE.
  • Wireless Broadband Systems.
  • Building Penetration and High Obstruction Deployments.
  • Smart Grid.

Specifications:

Frequency Range 700 to 2700 MHz
Gain 16 dBi
Horizontal Pattern Type Directional
Vertical Pattern Type Directional
Ground Plane Built-In
Color Black
Antenna Feeds One
Coax Length Variable
Coax Type Low Loss 200 Series
Connector Type F - N Female
Polarization Multi-Polarized
Power 100 Watts Input
Impedance 50 Ohms Nominal
Construction UV Stabilized Polymers, High Grade Aluminium
Environmental Conditions Outdoor or Indoor
Operation Temperature -40 to 85 deg C
Storage Temperature -40 to 85 deg C
Transport Temperature -40 to 85 deg C
IP Rating IP66
Length 16 in
Width 11 in
Radome Height N/A
Total Height 10 in
Weight 3.5 lbs
Hardware Included Down-Tilt Bracket
Summary Sector Antenna, 30 Degrees, 700 to 2700 MHz, White / Black, One Feed, 200 Series Coax Cable.

Reviews

Customer Reviews

Questions & Answers

QUESTIONS & ANSWERS

Have a Question?

Be the first to ask a question about this.

Ask a Question

Data Sheet / User Guide

Make An Offer

  • This field is required. Please enter a value.

  • This field is required. Please enter a value.

  • This field is required. Please enter a value.

  • This field is required. Please enter a value.

  • Input Correct Captcha

Warning

Note: For any signal booster to help, outside signal strength must be at least -110 dB or there must be a clear line of sight to a cell tower that is within twenty miles. Before ordering, please check outside signal level in decibels or ensure that you can make and hold a phone call at any good spot outside where you can mount an exterior antenna. Square footage stated in signal booster listings is based on good signal outside. If it is any weaker, the boosted sq. ft. area will be considerably lower, accordingly.

Kevin K. of Anderson, California gave the following review:

Website is easy to use with plain straight forward info but could have had more on testing signal strength to make sure you get a strong enough booster.

Therefore, please note that stated sq. ft. coverage is based on good signal outside. For best results: If outside signal is weak, we suggest choosing the next higher sq. ft. coverage kit. If outside signal is very weak, we suggest choosing the kit with even more higher sq. ft. range bracket. Basically, higher the sq. ft. bracket, the more powerful the signal amplifier with greater Gain as well as higher uplink and downlink output power.

If outside signal is too weak (weaker than -110 dB), submit request for cell coverage solution assessment. Upon receipt of questionnaire, we will perform residential or business site survey. This will help us determine the system that is needed to improve cell coverage. Then, we will create system design using that system such as femtocell, active or hybrid distributed antenna system (DAS), or other carrier feed signal enhancing method available that will work at your signal-challenged location. Finally, we will schedule for installation after equipment and installation service quote has been approved by you, or your company.

For non installation-included kits: Most home / office / building cell signal booster kits only include bracket to mount exterior antenna on outside wall, edge of roof, or existing pipe up to 2 inches in diameter. Mounting pole not included with most kits, unless stated specifically that it is included for free. Therefore, a mounting post must be purchased separately if you will require it to mount exterior antenna.
